Xr3000 Ignition Conversion System – Fast3000-0231 Kit

Description

XR3000 Ignition Conversion Kit

Suit Import and Universal 4, 6 and 8 Cylinder Applications.

FAST3000-0231

ST3000-0231

Operating voltage6 to 18 volts, reverse polarity protected,negative ground. Not compatible with 6 volt electrical systems as these may drop below 4 volts during cranking.Coil current limit4.5 amps internal short circuit protection limit set at 7 amps.RPM range6,500 RPMPrimary voltage output400 volts (inductive discharge)Primary energy output90 millijoules with PS91 coil.Peak spark gap current100 milliamps with PS91 coil.Spark duration2800 microseconds at 2,000 RPMDimensions5″L x 3″W x 1-1/2″H, 1-1/2 lbs.
